About this product

Our surface LED downlight squared, also called an LED ceiling light, offers standard lighting for the residential sector. Its greatest advantage is it is easy to install as no cuts need to be made. It has a stylish, discreet design, making it ideal for use in homes and indoor ceilings. This type of light fitting is used in general lighting for domestic use. It offers highly uniform, pleasant, reflection-free lighting.

Product Configuration

Select your preferred configuration from available options

26308-2180-01
Power8W
ControlON-OFF
Color TempCCT (2700-3000-4000)K
System Output547 (2) - 561 (3) - 633 (4) lm
Beam Angle120°
ColorBlack
26308-2183-90
Power8W
ControlON-OFF
Color Temp3000K
System Output561 lm
Beam Angle120°
ColorTechnical White
26308-2184-90
Power8W
ControlON-OFF
Color Temp4000K
System Output633 lm
Beam Angle120°
ColorTechnical White
26308-5183-90
Power8W
ControlTrailing Edge
Color Temp3000K
System Output561 lm
Beam Angle120°
ColorTechnical White
26308-5184-90
Power8W
ControlTrailing Edge
Color Temp4000K
System Output633 lm
Beam Angle120°
ColorTechnical White
26308-5180-01
Power8W
ControlTrailing Edge
Color TempCCT (2700-3000-4000)K
System Output547 (2) - 561 (3) - 633 (4) lm
Beam Angle120°
ColorBlack

Selected Configuration

Reference:
26308-2180-01
Power:
8W
Output:
547 (2) - 561 (3) - 633 (4) lm
Control:
ON-OFF
Color:
Black

Simple ON/OFF control, can be programmed with KNX systems

Technical Specifications

Aluminium
Material
Technical White, Black
Colours
8W
Power
3000, 4000, CCT (2700-3000-4000)
Color Temperature
960 lm
Luminous Flux
120°
Beam Angle
43
IP Rating
SMD 2835
LED Type
50000 hours
Lifespan
> 80
CRI
120 lm/W
Efficiency
Ø120 x 41
Dimensions
Fixed to the ceiling by rotation system, without screws or holes.
Observations
